Features

License

Licensed for testing and evaluation purposes. Please see the license agreement included in the sample project. You can use the source code of the tutorial if you are a licensed user of DayPilot Pro for JavaScript. Buy a license.

Dependencies

This quick start Angular project already includes daypilot-pro-angular package from npm.daypilot.org as a dependency:

npm install https://npm.daypilot.org/daypilot-pro-angular/trial/8.3.2864.tar.gz --save

Calendar Component


The event calendar component is defined in calendar/calendar.component.ts file.

The template uses <daypilot-calendar> tag to insert DayPilot event calendar at the specified location. The <daypilot-calendar> selector is defined in the DayPilotModule from "daypilot-pro-angular" package. DayPilotModule needs to be imported (see "Calendar Module" below).

@Component({
  // ...
  template: `<daypilot-calendar [config]="config" [events]="events" #calendar></daypilot-calendar>`,
  // ...
})

The calendar properties are defined using "config" object:

export class CalendarComponent implements AfterViewInit {

  // ...

  config: any = {
    viewType: "Week",
    startDate: "2017-05-01",
  };


}

The calendar data is defined using "events" object:

export class CalendarComponent implements AfterViewInit {

  // ...

  events: any[] = [];

  constructor(private ds: DataService) {
  }

  ngAfterViewInit(): void {
    var from = this.calendar.control.visibleStart();
    var to = this.calendar.control.visibleEnd();
    this.ds.getEvents(from, to).subscribe(result => {
      this.events = result;
    });
  }

}

Complete calendar/calendar.component.ts source:

import {Component, ViewChild, AfterViewInit} from "@angular/core";
import {DayPilotCalendarComponent} from "daypilot-pro-angular";
import {DataService} from "./data.service";{}

@Component({
  selector: 'calendar-component',
  template: `<daypilot-calendar [config]="config" [events]="events" #calendar></daypilot-calendar>`,
  styles: [``]
})
export class CalendarComponent implements AfterViewInit {

  @ViewChild("calendar")
  calendar: DayPilotCalendarComponent;

  events: any[] = [];

  config: any = {
    viewType: "Week",
    startDate: "2017-05-01",
  };

  constructor(private ds: DataService) {
  }

  ngAfterViewInit(): void {
    var from = this.calendar.control.visibleStart();
    var to = this.calendar.control.visibleEnd();
    this.ds.getEvents(from, to).subscribe(result => {
      this.events = result;
    });
  }

}

The ngAfterViewInit event handler uses DataService class to load the data. This quick start project uses a dummy DataService that returns an events array defined locally.

calendar/data.service.ts

import { Http, Response } from '@angular/http';
import { Injectable } from '@angular/core';
import { Observable } from 'rxjs/Rx';
import 'rxjs/Rx';
import {DayPilot} from 'daypilot-pro-angular';

@Injectable()
export class DataService {

  events: any[] = [
    {
      id: "1",
      resource: "R1",
      start: "2017-05-01T12:30:00",
      end: "2017-05-01T16:00:00",
      text: "Event 1"
    }
  ];

  constructor(private http : Http){
  }

  getEvents(from: DayPilot.Date, to: DayPilot.Date): Observable<any[]> {

    // simulating an HTTP request
    return new Observable(observer => {
      setTimeout(() => {
        observer.next(this.events);
      }, 200);
    });

    // return this.http.get("/api/events?from=" + from.toString() + "&to=" + to.toString()).map((response:Response) => response.json());
  }

}

Calendar Module

This project wraps the customized calendar component (calendar.component.ts) and the data service (data.service.ts) in a special module (calendar.module.ts). Note that the module imports DayPilotModule.

calendar/calendar.module.ts

import {DataService} from "./data.service";
import {HttpModule} from "@angular/http";
import {FormsModule} from "@angular/forms";
import {BrowserModule} from "@angular/platform-browser";
import {NgModule} from "@angular/core";
import {CalendarComponent} from "./calendar.component";
import {DayPilotModule} from "daypilot-pro-angular";

@NgModule({
  imports:      [
    BrowserModule,
    FormsModule,
    HttpModule,
    DayPilotModule
  ],
  declarations: [
    CalendarComponent
  ],
  exports:      [ CalendarComponent ],
  providers:    [ DataService ]
})
export class CalendarModule { }
